| TECHNICAL DATA (mm) | MARK F2 5181 | MARK F2 6191 | MARK F2 71102 | MARK F2 75107 |
| Maximum Sheet size | 510 mm x 810 mm | 610 mm x 910 mm | 710 mm x 1020 mm | 750 mm x 1070 mm |
| Minimum Sheet Size | 400 mm x 400 mm | 400 mm x 400 mm | 400 mm x 400 mm | 400 mm x 400 mm |
| Stock Range | 0.05 mm To 0.5 mm | 0.05 mm To 0.5 mm | 0.05 mm To 0.5 mm | 0.05 mm To 0.5 mm |
| Feeder Pile Height | 950 mm | 950 mm | 950 mm | 950 mm |
| Delivery Height in Coating M/c. From Floor | 800 mm To 1050 mm | 800 mm To 1050 mm | 800 mm To 1050 mm | 800 mm To 1050 mm |
| Feeding Height in Feeder from Floor | 1065 mm | 1065 mm | 1065 mm | 1065 mm |
| Max. Speed* | 12,000 SPH | 12,000 SPH | 12,000 SPH | 12,000 SPH |
| Drive motor A.C Variable | 1 HP | 1 HP | 1 HP | 1 HP |
| Feeder Pile Motor A.C | 1 HP | 1 HP | 1 HP | 1 HP |
| Pump Motor For Feeder | 3 HP | 3 HP | 3 HP | 3 HP |
| Floor Space Without Preloader | 1800 (L) x 1450 (W) x 1500 (H) | 2000 (L) x 1550 (W) x 1500 (H) | 2200 (L) x 1650 (W) x 1500 (H) | 2250 (L) x 1700 (W) x 1500 (H) |
