Contact SupplierWe Offer aviation plug,small connector have the features of small size,light weight,convenient application with threaded-coupling connection.It can be interchanged with Russian type PC, They are widely used for the electrical connection between electrical equipments and instruments. Product Ordering
PC -- 4 Z
1 2 3
1.Name PC series connectors
2.Number of contacts 4,7,10,19,32,50
3. T-plug,Z-receptacle,P-Cable shell,ZP- cable receptacle
Technical characteristics
Temperature
Relative humidity
Atmosphere
Vibration
Shock
Endurance
-40°C~
+105°C
(92~98)%,
at40+2°C
101.33KPa~6.67Pa
10~2000Hz,
196m/s²
392m/s²
500 cycles
Current
Voltage
Contact resistance
Contact Ø
3A
200V
≤8mΩ
Ø1mm
Environment
Voltage proof
Insulation resistance
Normal
1000V
≥1000MΩ
High temperature
700V
≥500MΩ
Moisture
500V
≥50MΩ
Low pressure
200V
-
