total weight 5800 kg
overall dimension 9000x2300x2900 mm
turning radius 5000 mm                   Â
backhoe bucket capacity 0.3 cbm
loading bucket capacity 1.0 cbm
fuel consumption 224 (gkw.h)
wheelbase 2600
wheel tread 1160
ground clearance 260 mmmodel yto
no. Of cylinders, type 4 cylinders in line, water cooled, turbo charged
bore and stroke 102x120 (mm)
displacement 3.261l
rated powerrotating speed 74.9kw 2200rpm
transmission system Â
hydraulic torque converter xiniu
axle kaichuang brand
drive method 4x2 or 4x4
speed Â
gears 4 forward 1 reverse
max. Speed 40kmh
hydraulic system Â
hydraulic pump single gear pump
flow rate 126 lmin
pilot joystick handler jeil brand (import from south korea)
main valve ruilong brandÂ
pilot pump gear pump
voltage 24 v
front wheels (size & ply rating)Â 9.00-20
rear wheels (size & ply rating)) 9.00-20
diesel fuel tank 120 l
hydraulic system fluid 125 l
backhoe part Â
backhoe bucket width 560 mm
backhoe bucket weight 185 kg
maximum outrigger width (extended)Â 2400 mm
minimum outrigger width (transport) 2020 mm
loader part Â
bucket width 2000 mm
bucket weight 260 kg
operating range Â
loader Â
maximum bucket reach 3500 mm
maximum loading height 3200 mm
maximum loader dumped height 2550 mm
maximum digging depth 15 mm
backhoe Â
boom length 3100
bucket arm length 2100
maximum dumping height 4390 mm
maximum bucket reach 6080 mm
maximum digging depth 3400 mm
maximum digging distance 5800 mm
