Ball Valve Testing Machine

Get Latest Price

ConditionNew
SizeStandard
MOQAs Per Client Requirement
GradeAA
Supply TypeManufacturer, Supplier, Retailer
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Company Information

Balaji Hydro Tech

Gondal, Rajkot, Gujarat

4.0/5

(1)

View Number

Member Since 14 Years
Nature of Business Retailer
GST No. 24AFHPR1742Q1ZZ

Ask for more detail from the seller

Contact Supplier

Report incorrect details

View Company Details

Product Details
Company Details

We offer our clients a safe payment procedure as we have both Online and Offline Payment Processing suiting the needs of the clients. In order to deliver a high quality lot of products, we make use of the best available resources and raw material. Also, we make sure that the material is sourced from the genuine vendors only.

We also Manufacturer on Customer's requirement. (SPM)
Operating System with Push Button Penal Control (Standard).

Details

Operating System with PLC CNC (Optional)
Cylinder Locking System (Screw Type)
Safety Feature: Hand Entry Resist Sensor, Body Safety Guards Cover, etc.
Easy Operation.
Very Low Maintenance.
Heavy Body Construction.
High Durability & Reliability.
High Quality & Performance.
Very Low Maintenance.
With Barcode Scanning Technology.
Standard Brand Raw Materials (Available everywhere in World).
Pump & Valve Make: Veljan Denison, Rexroth, Yuken.
Hydraulic System Make: Jacktech, Poly Hydrone.
Electric Moto Make: Siemens, ABB or Havells. IE2 Standard or Higher.
Cylinder Hard Chrome Plated, Grinding & Honing.
Cylinder Seal: Chevron Seal, Wiper Seal, ‘O’ Ring, Road Seal, Bore Seal (‘U’ Seal) & Guide Strip.
Cylinder Seal Make: Kastas.

Technical Specification

Model	Horizontal Hydraulic Press
Body Type	Two Pillars – Horizontal.
Cylinder Bore	220 mm.
Cylinder Rod	180 mm.
No. of Cylinder	Single Cylinder.
Main Cylinder Stroke	1000 mm.
Ram To Table Gap	Min.: 1600 mm – Max.: 2500 mm.
Site Clearance	1500 mm.
Center Height	1000 mm.
Power Pack	Pressure Control Valve, Pressure Locking Valve and Pressure Switch, Solenoid Valve
Maximum Working Pressure	200 kg.
Gauges List	Meter dial: 280 kg. High Pressure: 200 kg. Meter dial: 70 kg. Low Pressure: 32 kg. Pneumatic dial: 0 – 21.
Oil Tank Capacity	100 Liter. (Approx.)
Valve	Solenoid Valve Yuken make.
Electric Motor	7.5 HP (1440 rpm) Make ABB, Havells & Siemens.
Power Supply	415 V, 50 Hz, 3 Phase.
Standard Accessories	Breather, Oil Level, Section Filter, Liquid Feed Pressure Gauge.
Operating System	Motor On/Off, Emergency Stop Button, Up & Down Push Button and Cylinder Stroke Adjustable with Proxy Sensor and RYB Indicator.
