We offer a high-quality Ball Valve with Threaded End, designed for reliable performance in various applications. This Type - Ball Valve features a Threaded End Connection, suitable for easy installation. With a Pressure Rating of 150 PSI and Temperature Rating up to 200°F, it ensures efficient operation. The Lever Handle provides easy control, while the Seal Material - PTFE ensures a tight seal. This Ball Valve is capable of handling a Maximum Pressure of 150 PSI and a Maximum Temperature of 200°F, making it a dependable choice for your manufacturing needs.
| NO. | DESCRIPTION | QTY. | MATERIAL |
|---|---|---|---|
| 1 | BODY | 1 | PP / ISO.PP/ PVDF / ETFE |
| 2 | END PIECE | 2 | PP / ISO.PP/ PVDF / ETFE |
| 3 | SPINDLE | 1 | EN-8 INSERTED PP/ ISO.PP / PVDF / ETFE LINED |
| 4 | HANDLE | 1 | MS EPOXY COATED WITH FLEXIBLE PVC SLEEVE |
| 5 | BALL | 1 | PP / ISO. PP / PVDF / ETFE |
| 6 | FLANGE SEAL | 2 | EPDM / VITON / PTFE / NEOPRENE |
| 7 | SPINDLE SEAL | 2 | EPDM / VITON / PTFE / NEOPRENE |
| 8 | SEAT | 2 | PTFE |
| 9 | FASTENERS | - | MS GALVANISED / SS-304 / SS-316 |
| 10 | SPINDLE BOLT | 1 | MS GALVANISED / SS-304 / SS-316 |
| 11 | SPINDLE BUSH | 1 | PTFE |
