Heads
| 1 Horizontal & 1 Vertical | |
| Type of Main Centre | Fixed |
| Type of Head | Fixed |
| No. of axis | 3 (X - Longitude, Z - Vertical & Z-1 - Vertical for Depth) |
| Travel of 'X' axis from Centre of Horizontal Head to centre of Vertical Head | 130 mm |
| Vertical 'Z' axis Movement | Screw |
| Vertical 'Z-1' axis for depth | 5.5 mm |
| Horizontal Spindle Motor | 0.17 HP / 2800 RPM |
| Horizontal Spindle Speed | 5600 RPM |
| Vertical Spindle Motor | 0.17 HP / 2800 RPM |
| Vertical Spindle Speed | 6500 RPM |
| Net / Gross Weight (kgs.) | 120 / 150 |
| Dimensions (mm) | 590 x 590 x 790 |
| Shipping Volume (m 3 ) | 0.30 |
