Belt Sintering Machine Ds90

We are offering belt sintering machine.
belt sintering machine is most widely used in metallurgy and steel enterprises in china as a sintered models. It’s reliable and practical, with advanced technology. Belt sintering machine is built by trolley, drive unit, raw materials and bunk feeding device, bellows and the sealing device, dust discharge device, a main exhaust pipe and skeleton. Can be designed and manufactured according to the needs of users.
scope
it mainly applies to the sintering treatment in large or medium-sized sinter plant with iron ore powder.
main specifications
36m2, 52m2, 65m2, 72m2, 90m2, 105m2
main technical parameters
specification
ds36m2
ds52m2
ds65m2
ds72m2
ds90m2
ds105m2
amount of material(th)
85-100
125-140
155-175
170-195
215-245
250-285
effective sintering area(m2)
36
52
65
72
90
105
effective sintering length(m)
24
26
30
36
36
35
center distance(m)
34.3
34.25
36.25
42.25
48.745
47.745
size of trolley(m)
1.7x1
2x1
2.2x1
2.2x1
2.5x1
3x1
speed of trolley(mmin)
1-3
1-3
0.6-1.9
0.8-2.4
0.84-2.51
0.6-1.8
weight(t)
309
435
570
636
796
922
