Bharath Drone Detection Radar

Sold By : IoTechWorld Avigation Pvt. Ltd.

Product Specifications

Brand NameBharath
ApplicationDrone Obstacle Detection And Terrain Mapping
FeatureTerrain Following,Collision Avoidance,Object Detection,Terrain Mapping,Enhanced Safety,Efficient Flight,Precise Agriculture,Situational Awareness,Autonomous Operation,Increased Reliability
Country of OriginIndia
Number Of FlowerRadar System
Frequency Band77-81 GHz
Operating Temperature-40°C To +65°C
IntegrationSeamless Integration With Drone Flight Controllers
Field Of View60 Degrees
TechnologyMillimeter-wave Radar
Range30m
Temperature Range-40°C To +65°C
PurposeDetect And Avoid Obstacles In Drone Flight Path
Environmental ResilienceOperates In Various Weather Conditions
Supply TypeManufacturer, Exporter, Supplier

Preferred Buyer From : All over the world

Product Overview

IoTechWorld Avigation designs “Radar” (Bharath Radar) systems, “Terrain following” & “Collision Avoidance” which provides unmatched accuracy, reliability, and performance.

Navigate complex environments with confidence using our radar, which provides accurate terrain mapping and obstacle detection.

Advanced sensing technology, Empowering your Drone.
Provides object detection & terrain mapping.
77-81 GHz frequency band, 30m range, & 60° field of view.
Reliability & Performance, even in challenging environments (-40°C to +65°C).

Additional Information

Enhanced Safety

Collision prevention through real-time terrain mapping and obstacle detection.

Efficient Flight

Optimized flight paths for reduced energy consumption and increased range.

Precise Agriculture

Accurate data collection for optimized farming practices and yield improvement.

Situational Awareness

Real-time information about the surrounding environment.

Autonomous Operation

Real-time information about the surrounding environment.

Increased Reliability

Reduces reliance on manual piloting for safer and more consistent operations.

Component Specifications

Parameter	Specification (Terrain)	Specification (Collision)
Azimuth Angle	±15°	±50°
Elevation Angle	±5°	-4˜+8°
Max EIRP (dBm)	16	16
Ranging Accuracy (m)	±0.1	±0.1
Detect Range (m)	0.10-20	02-30
Range Resolution (m)	0.12	0.12
Transmitting Frequency (GHz)	77-81	77-81
Refresh Rate (Hz)	30	30
Bandwidth (GHz)	4	4
Operating Voltage (VDC)	4.5~5.5VDC	4.5~5.5VDC
Operating Temperature	-40°~+65°	-40°~+65°
Data Interface	CAN	CAN
Power Consumption	2.08	2.08
Size (mm)	88.766.415.2	88.766.415.2
Weight (g)	90	90
