| Model | TR-24B | TR-42D | TR-80A |
| Work Piece (in Feed) | 3-24 mm | 3-50 mm | 10-80 mm |
| Max. Pitch of Thread (Standard V Thread) | 3 mm | 5 mm | 10 mm |
| Max. Serrations Pitch | 1.0 mm | 1.6 mm | 3 mm |
| Max. Die. Width | 80 mm | 150 mm | 200 mm |
| Max. Through Feed Thread Length | 6 meter | 6 meter | 6 meter |
| Max. Rolling Force (infinitely adjustable) | 6 tons | 16/20 tons | 30 tons |
| Spindle Axis Swivel for through Feed | 50 | 50 | 120 |
| Roll Spindle | 40 mm | 4 mm | 69.85 mm |
| Max. Rolling Die | 120 mm | 180 mm | 220 mm |
| Roll Spindle Speed (RPM) | 60/90 | 20/40/60 | 16/22/34/73/110/150 |
| Main Motor (H.P.) | 3 | 5/7.5 | 15 |
| Hydraulic Power Pack Motor (H.P.) | 1 | 2/3 | 3 |
| Coolant Pump | 1/8 H.P. | 1/8 H.P. | 1/2 H.P. |
| Electrical Connection | 415 V. 50 Hz, 3 Phase | 415 V. 50 Hz, 3 Phase | 415 V. 50 Hz, 3 Phase |
| Appx. Weight | 1000 Kg. | 2200 Kg. | 3500 Kg. |
