Bimetallic Screw and Barrel

Bimetallic screw and barrel
specification:
screw diameter:î¦15mm-î¦360mm screw max length:8000mm
barrel diameter:î¦15mm-î¦360mm barrel max length:7000mm
bimetallic alloy material:
1.ni-based alloy
2.fe-based alloy
3.co-based alloy
4.nico-based alloy
5.tungsten carbige
bimetallic screw barrel processing method:
plasma alloy coating spraying or wcco whole spray welding
bimetallic barrel production method:centrifugal casting (inlay alloy)
outstanding features of bimetallic screw and barrel:
1)hardness hrc50-65
2)outstanding corrosion-resistance.
3)hardness layer reaches 1.5 mm thickness.hardness does not decrease with depth.
4)hardness does not decrease under normal temperature.
5)abrsion resistance wear resistance on the hardened layer is 2~3 times higher than that treated by conventional heat treatment.
