Contact SupplierWall Mounted Dental Microscope is commonly used in dental offices to allow for precise and efficient magnification as and when required. It can be mounted with ease near a reclining chair as required and also has binocular tubes which are inclined at 45 degrees. There are also three steps of magnification available which can be adjusted with ease. The inbuilt illumination provided in the form of halogen lamps and a fibre optic light guide also helps to make our product an attractive choice.
Details : We are offering wall mount dental microscope total distance from wall to optical head - 120cms approx. Technical specifications - binocular tubes : fixed inclined at 45degree eye pieces - 10x wide field 3 step magnifications - 5x, 10x & 20x objective lens : f=200mm field of view : 50mm ipd adjustment : 55mm to 75mm fine focusing - manual focusing knob. illumination - 15v150w twin halogen lamps with 100% coaxial through the lenses focused fiber optics light guide 1.5 meter, bright light more than 80,000 lux, maximum at standard condition. field of illumination - 70mm arm - counter balanced pantographic arm with 320 degree rotation. Vertical range of counter balanced arm - 250mm to 300mm weight - 18kg (approx.) without packing power - ac 220v, 5060hz. (110v on request)
