Technical Parameters
Model BM-10T BM-10T7IN BM-12T7INT BM-13T7IN
Application Marking surface Especially for Large workpiece Car VIN code marking
Marking speed 2-5 characters(2x2mm)/s
Marking depth 0.02-2 mm (adjustable)
Repeat precision 0.02-0.04 mm
Stylus Pin Hardness HRA92/HRA93
Stroke Frequency 300times/s
Marking area 80x30/130x30mm(optional)
Power 300W
Power type Pneumatic/Electric
Connection USB and RS-232
Controller  windows 7&windows XPÂÂ
 7.5"LCD touch screen controllerÂÂ
Operation software ThorX6/7 or KING8
Work voltage AC220V±10%~50Hz  AC110V±10%~50Hz
Support software format support multipple graphics and fornts, compatible with autoCAD coreDarw
Feature:
ï¬Pneumatic scribing system generating high quality continuous style marks on materials ranging from plastics to hardened steel
ï¬Extreme low noise operations
ï¬Rigid column and robust ball screw mechanism guarantees the highest quality of marks
ï¬Equipped with rotary device and programmed batch height positioning
ï¬Low running costs and virtually no consumable costs
ï¬Very large embedded graphical display
ï¬Simple to use menu system software, On-screen mark preview and trial-run features.
ï¬Advanced standard features incl. serial numbering, passwords, arc marking, time/date and logo marking etc.
ï¬Various communication ports and I/O
ï¬Wide Range of Options
Suitable materials and application:
It is widely used in fields that have high requirement on depth. such as motorcycle, electric cycle&bicycle manufacturers,aeronautics, electronic,war and light industry, mould steel, Staineless steel iron. copper ,VIN code aluminum and plastic parts and various kinds of nameplate, Direct Part Marking (DPM) ,Compliance Marking ,DataMatrix Coding,VIN Coding,Programmable Marking
