High Pressure Round Polished Plain Blind Flanges, For Fittings Use, Certification : Isi Certified

₹ 100 - ₹ 500 / Piece

MOQ100 Piece
MaterialStainless Steel, Carbon steel, Duplex Steel, Nickel Alloy, Inconel, Incoloy, Hastelloy & Monel Weld
Flange TypePlain
FinishingPolished
SpecialitiesStrong Construction, Rust Proof
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Company Information

5.0/5

Member Since 2 Years
Nature of Business Manufacturer
GST No. 27AHEPM6224H1ZD

Ask for more detail from the seller

Report incorrect details

Product Details
Company Details

Country of OriginIndia
Range½” (15 NB) To 48” (1200NB)
Pressure Ratings150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS ASA 150, ASA 300, PN 6, 10, 16, 25, 40, 64, 100, 16
Flange TypePlain
CertificationISI Certified
PressureHigh Pressure
FinishingPolished
UsageFittings Use
SpecialitiesStrong Construction, Rust Proof
MaterialStainless Steel, Carbon steel, Duplex Steel, Nickel Alloy, Inconel, Incoloy, Hastelloy & Monel Weld
ShapeRound

Hindustan pipes & Fittings is a dynamic group, which was established over a decade ago to cater to growing demands of Blind Flanges standards in ASME / ANSI B16.5 Flanges,ASME/ANSI B16.47 etc in all materials like Stainless Steel , Carbon Steel & High Nickel Alloys. We Manufacture, Export and Supply Flanges which meets with national and international quality standards and producing base which owns equipments conforming to international technical level and is well equipped with a whole set of advanced plasma refining equipments.

Class 150 SPECTACLE BLINDS FLANGES

Class 150 SPECTACLE BLINDS FLANGES
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W
44928	45	16	60	3	38
44989	54	21	70	3	38
1	64	27	80	3	38
1¼	73	42	90	6.4	38
1½	83	48	100	6.4	38
2	102	61	120	6.4	51
2½	107	73	140	6.4	51
3	133	89	150	6.4	64
3½	159	102	175	9.7	64
4	172	114	190	9.7	64
5	194	141	215	9.7	76
6	219	168	240	12.7	76
8	276	219	300	12.7	76
10	337	273	360	15.7	102
12	406	324	430	19.1	102
14	448	356	475	19.1	108
16	511	406	460	22.4	108
18	546	457	580	25.4	114
20	603	508	635	28.4	121
24	714	610	750	31.8	140
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W

Class 300 SPECTACLE BLINDS FLANGES

Class 300 SPECTACLE BLINDS FLANGES
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W
44928	51	16	65	6.4	38
44989	64	21	80	6.4	38
1	70	27	90	6.4	38
1¼	79	42	100	6.4	38
1½	92	48	115	6.4	38
2	108	61	125	9.7	51
2½	127	73	150	9.7	51
3	146	89	170	9.7	64
3½	162	102	185	12.7	64
4	178	114	200	12.7	64
5	213	141	235	15.7	76
6	248	168	270	15.7	76
8	305	219	330	22.4	76
10	359	273	385	25.4	102
12	419	324	450	28.4	102
14	483	356	515	31.8	108
16	536	406	570	38.1	108
18	594	457	630	41.1	114
20	651	508	685	44.5	121
24	772	610	810	50.8	140
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W

Class 600 SPECTACLE BLINDS FLANGES

Class 600 SPECTACLE BLINDS FLANGES
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W
44928	51	16	65	6.4	38
44989	64	21	80	6.4	38
1	70	27	90	6.4	57
1¼	79	37	100	9.7	57
1½	92	43	115	9.7	67
2	108	55	125	9.7	57
2½	127	67	150	12.7	67
3	146	83	170	12.7	67
3½	159	96	185	15.7	76
4	191	108	215	15.7	76
5	238	135	265	19.1	86
6	264	162	290	22.4	86
8	318	212	350	28.4	95
10	397	265	430	35.1	105
12	454	315	490	41.1	105
14	489	346	525	44.5	114
16	562	397	605	50.8	124
18	610	448	655	53.8	133
20	679	497	725	63.5	133
24	787	597	840	73.2	152
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W

Class 900 SPECTACLE BLINDS FLANGES

Class 900 SPECTACLE BLINDS FLANGES
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W
44928	60	16	80	6.4	38
44989	67	21	90	6.4	41
1	76	27	100	6.4	57
1¼	86	37	110	9.7	57
1½	95	43	125	9.7	67
2	140	55	165	12.7	57
2½	162	67	190	12.7	67
3	165	83	190	15.7	67
4	203	108	235	19.1	76
5	244	135	280	22.4	86
6	286	162	320	25.4	86
8	356	212	395	35.1	95
10	432	265	470	41.1	105
12	495	315	535	47.8	105
14	518	346	560	53.8	114
16	572	397	615	60.5	124
18	635	448	685	66.5	133
20	696	497	750	73.2	133
24	835	597	900	88.9	152
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W

Class 1500 SPECTACLE BLINDS FLANGES

Class 1500 SPECTACLE BLINDS FLANGES
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W
44928	61	16	80	6.4	38
44989	67	21	90	9.7	41
1	76	27	100	9.7	64
1¼	86	35	110	9.7	64
1½	95	41	125	12.7	70
2	140	53	165	12.7	70
2½	162	63	190	15.7	76
3	172	78	205	19.1	76
4	206	102	240	22.4	89
5	251	128	290	28.4	89
6	279	154	320	35.1	89
8	349	203	395	41.1	102
10	432	255	480	50.8	114
12	518	303	570	60.5	114
14	575	333	635	66.5	127
16	638	381	705	76.2	133
18	702	429	775	85.9	146
20	752	478	830	95.3	152
24	899	575	990	111.3	178
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W

Class 2500 SPECTACLE BLINDS FLANGES

Class 2500 SPECTACLE BLINDS FLANGES
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W
44928	67	16	90	9.7	38
44989	73	21	95	9.7	41
1	83	27	110	9.7	64
1¼	102	35	130	12.7	64
1½	114	41	145	15.7	70
2	143	53	170	15.7	70
2½	165	63	195	19.1	76
3	194	78	230	22.4	76
4	232	102	275	28.4	89
5	276	128	325	35.1	89
6	314	154	370	41.1	89
8	384	198	440	53.8	102
10	473	248	540	66.5	114
12	546	289	620	79.2	114
NPS	Outside Ø A	Inside Ø B	Centerline C	Thickness t	Web Width W
