Contact SupplierWe are offering body scale load cell
capacity: 30~300kg
materiail: aluminum
dimension: subject to capacity
accuracy class: 0.05 % r. O.
It is a aluminum sensor, and apply for low profile infant and adult medical scales,low profile platform scales,personal scales,airport bagagges scales,postal scales etc.easy to mouting, high accuracy.
Features:very low profile
matched output
item specification
rated loading 30kg~300kg
dimension w2*t*70
rated output (1.0-2.0)±10%mvv
zero balance ±0.1mvv
non-linearity ±0.05%of r.o.
hysteresis,repeatability ±0.05%of r.o.
creep in 2 min. ±0.05%r.o.2min
temp. Effect on output ±0.05%r.o.10℃
temp. Effect on zero ±2%r.o.10℃
inout resistance 1130±20ω
output resistance 1000±10ω
safe overload 150%.r.c.
insulation resistance ≥2000mω
operating temp. Range -10to+40℃
excitation,recommended ≤10vdc
cable,length four color pvc:φ0.8mm*60cm.
