Bolt Thread Rolling Machine

Specification:
model No.: Imc-25
max. Pitch Can Be Rolled (in Mm): 2.5
max. Dia Can Be Rolled in Feed (in Mm): 25
max. Dia Can Be Through Feed (in Mm): 16
max. Rolling Length in Feed (in Mm): 80
max. Rolling Length Through Feed: Indefinite
max. Outer Dia Thread Rolls (in Mm): 150
spindle Dia (bore Dia) (in Mm): 54
max. Rolling Force: 8 Tons
power for Roll Spindles: 3 H.p. 1400 Rpm
power for Hydraulic Pump: 2 H.p.
power for Coolant Pump: 0.1 H.p.
model No.: Imc-40
max. Pitch Can Be Rolled (in Mm): 3.5
max. Dia Can Be Rolled in Feed (in Mm): 40
max. Dia Can Be Through Feed (in Mm): 28
max. Rolling Length in Feed (in Mm): 150
max. Rolling Length Through Feed: Indefinite
max. Outer Dia Thread Rolls (in Mm): 180
spindle Dia (bore Dia) (in Mm): 54
max. Rolling Force: 13 Tons
power for Roll Spindles: 5 H.p. 1400 Rpm
power for Hydraulic Pump: 3 H.p.
power for Coolant Pump: 0.1 H.p.
model No.: Imc-50
max. Pitch Can Be Rolled (in Mm): 4.0
max. Dia Can Be Rolled in Feed (in Mm): 50
max. Dia Can Be Through Feed (in Mm): 35
max. Rolling Length in Feed (in Mm): 150
max. Rolling Length Through Feed: Indefinite
max. Outer Dia Thread Rolls (in Mm): 200
spindle Dia (bore Dia) (in Mm): 69.85
max. Rolling Force: 15 Tons
power for Roll Spindles: 7.5 H.p. 1400 Rpm
power for Hydraulic Pump: 5 H.p.
power for Coolant Pump: 0.1 H.p.
model No.: Imc-80
max. Pitch Can Be Rolled (in Mm): 5.0
max. Dia Can Be Rolled in Feed (in Mm): 80
max. Dia Can Be Through Feed (in Mm): 40
max. Rolling Length in Feed (in Mm): 150
max. Rolling Length Through Feed: Indefinite
max. Outer Dia Thread Rolls (in Mm): 220
spindle Dia (bore Dia) (in Mm): 69.85
max. Rolling Force: 24 Tons
power for Roll Spindles: 10 H.p. 1440 Rpm
power for Hydraulic Pump: 5 H.p.
power for Coolant Pump: 0.1 H.p.
model No.: Imc-100
max. Pitch Can Be Rolled (in Mm): 5.5
max. Dia Can Be Rolled in Feed (in Mm): 100
max. Dia Can Be Through Feed (in Mm): 50
max. Rolling Length in Feed (in Mm): 150
max. Rolling Length Through Feed: Indefinite
max. Outer Dia Thread Rolls (in Mm): 220
spindle Dia (bore Dia) (in Mm): 69.85
max. Rolling Force: 30 Tons
power for Roll Spindles: 12.5 H.p. 1440 Rpm
power for Hydraulic Pump: 5 H.p.
power for Coolant Pump: 0.1 H.p.
model No.: Imc-120
max. Pitch Can Be Rolled (in Mm): 8
max. Dia Can Be Rolled in Feed (in Mm): 125
max. Dia Can Be Through Feed (in Mm): 70
max. Rolling Length in Feed (in Mm): 150
max. Rolling Length Through Feed: Indefinite
max. Outer Dia Thread Rolls (in Mm): 220
spindle Dia (bore Dia) (in Mm): 69.85
max. Rolling Force: 40 Tons
power for Roll Spindles: 15 H.p. 1400 Rpm
power for Hydraulic Pump: 7.5 H.p.
power for Coolant Pump: 0.1 H.p.
