Boundary Layer Flow

Boundary Layer Flow Technical Description The experimental set-up is placed in the Air Flow Studies unit with only a few actions. The model consists of a transparent tube in which the flat plate is placed. Above the plate, a vertically adjustable Pitot tube is fitted using which the flow speeds at the plate can be measured. The Pitot tube can be fitted on a holder in 3 positions along the plate. The Pitot tube is connected to the manometer belonging to the studies unit.
