Brass Earth Bars, Brass Neutral Bars

We are offering Brass Earth Bars and Brass Neutral Bars. Neutral link bars also known as ground bars & earth bars are multiple wire, mechanical compression, wire connection bars used in industrial, commercial and residential electrical panels to terminate the many neutral wires which return from the various load circuitry in buildings, electrical machinery, control panels, big screen displays, solar panels, and many other applications involving many circuits. Neutral bars are simple mass wire termination devices that allow many wires to be terminated in one place, usually at the main service panel, in a small space and at low cost.
designed for easy installation, our product range consists of active, neutral and earth link bars, single connectors, as well as blocks and strips, in a wide range of sizes for commercial and industrial switchboards. Drilling and tapping are carried out using state-of-the-art equipment & tools that ensures the highest quality products. We have an excellent reputation for specializing in jobbing work.
we can provide neutrals/ground bars in brass as well as other copper alloys. Different cross sections, different screw and configurations can be custom made. Please forward your requirements & we can manufacture as per your specifications.
product information & features:
•material: brass (cuzn39pb3) & other specified alloys.
•finish: self color natural, nickel plating as required.
•number of tunnels or poles: 6, 9, 12, 18, 24, 30, 36, 42, 48, 54, 72, 96.
•overall length from 72mm upto 996 mm are currently being manufactured at our factory. Length can be increased as specified.
•we manufacture bars suitable for 70amp, 90a, 110a, 165a through 350amp
•screws: steel multi-head, zinc plated – headless set screw, headed slotted machine screw, headed machine screw combination & square slot, headless hex socket, etc.
•numbered as well as un-numbered bars available on request.
•single screw tunnel as well as double screw tunnels.
•chamfered edges & tunnel holes.
•wire range: american wire gauge awg 4-14 cu (copper wire), 4-12 al (aluminum wire) 2/0-14, 300mcm-6, dual rated, solid & stranded, rigid or semi rigid stranding. Amp rated at 85 amps for copper wire and 70 amps for aluminum wire.
any kind of customized bars are can be developed and supplied exactly as per clients drawings & specifications.
also available: custom earth bars, custom neutral bars, neutral bar mounting feet, copper bus bars, terminal blocks, custom link bars, switchboard components
