Bucket Elevator

Product introduction:
bucket elevator is composite by the shell, traction parts (chain), hopper, driving wheel (head wheel), bend wheel (tail wheel), tensioner, guider, feeding end (inlet) and the discharge end (outlet).
A, cylindrical bucket: deep bucket, bucket opening was 65 º tilt, high depth, and for drying, good flow, for good scattered granular material delivery
shallow bucket: opening was 45 º tilt, low depth, for mobility and wet granular materials.
B, angular bucket: the side extent out the end board to form guard board, when discharging, the material flow along the guard board and floor, for the delivery of viscosity, large and heavy block of bulk materials
traction parts
(a) rubber belt: flexible gasket fixed with screws and connected to the belt end, with bucket width more than 35 ~ 40mm, generally belt can deliver materials no more than 60 degree celsius, heat-resistant belt can reach 150 degree celsius.
(b) chain: the single chain connected to the back board of hopper;
the double chains connect on both sides of the hopper board. Chain bucket elevator applies single chain when the bucket width is 160 ~ 2500mm, and applies double chains when the bucket width is 320 ~ 630mm, the main drawback of chain bucket elevator is high wear and frequency maintenance.
Features and benefits:
the dive power is small; to adopt inflow feeding, induction discharge. Large capacity bucket by intensive layout. Seldom return material and excavating.
2. Widely working range. It has fewer requests on materials, not only suitable for powder, granular, but enhances the high-mill cut materials and tightness, less environmental pollution.
3. Operating reliability. It has an advanced design principles and processing methods to ensure the reliability of machine operation, trouble-free time more than 20 thousand hours, high lift height, running smoothly, so it can upgrade to a higher height.
