Contact Supplier| Single Core PVC Unsheathed Electrolytic Copper Industrial | |||||
|---|---|---|---|---|---|
| Flexible Cables UP to 1100 V. Generally Conforming To IS 694:1990 | |||||
| Nominal c/s Area of Conductor In Sq. mm. | Conductor Construction No. / mm. | Nominal Insulation Thickness In mm. | Approx. Overall Diameter In mm. | Current Rating At 40°C in Amps. (#) | Max. D/C Resistance Per. Km. @ 20°C Ohm. / Km. (*) |
| 6.00 | 84/0.30 | 0.9 | 5.3 | 31 | 3.08 |
| 10.00 | 140/0.30 | 1.0 | 6.7 | 42 | 1.83 |
| i 6.00 | 225/0.30 | 1.0 | 8.1 | 57 | 1.15 |
| 25.00 | 354/0.30 | 1.2 | 10.0 | 72 | 0.727 |
| 35.00 | 490/0.30 | 1.2 | 11.5 | 90 | 0.524 |
| 50.00 | 700/0.30 | 1.4 | 13.0 | 115 | 0.387 |
