Contact SupplierSize : 11⁄2” to 48”
Valve Type : Centric Disc/ Double Flanged/ Damper/ Off –Set Disc
Body : Cast Steel/ Ductile Iron/ Gry Iron/ CF8/ CF8M/ CF 3M
Disc : CF8/ CF 8M/CF 3M/ SG Iron with Teflon/ Nylon Coated & Rubber Line
Seat : Nitrile/ EPDM/ Viton/ Hypeion/ Silicon/ Neopren/ Metal to Metal for Double
Flange Damper valve
Shaft : AISI 410/ AISI 304/ AISI 316/ AISI 316
Body : Short Wafer type/ Double Flange for Double Flange Damper valve
End connection : Wafer type End connection
Operating : Hand Lever, Worm Gear, Pneumatic Actuated, Electrical Actuated
Actuator Details
Type : Rack and Pinion type
Actuation : Double Acting/ Single Acting (Spring Return)
Mounting Std : ISO 5211 An International Standard
Pneumatic connections : NAMUR Standard
