BV Bin Vibrator

Fluidizer pads located within the hopper are operated by pulsing air on and off. As the pads are pushed out with airflow, they will vibrate the sides of the hopper and push air outwards amongst the sides of hopper in order to increase or resume product flow by breaking loose compacted or sluggish materials from the hopper cone.
STANDARD CONSTRUCTION FEATURES
Cast ductile iron housing
Impacting type model to produce a metal-to-metal contact at the mounting plate which is the most effective in eliminating difficult flow problems
Air operated
Designed for a maximum hopperbin capacity of 5 to 15 cubic feet
Filtered and lubricated compressed air at 60 PSIG maximum required and is to be supplied by buyer
