Contact SupplierMain specification
hf generator 110kv, 3.5kw , 40khz
fluoroscopy mode fluoroscopy mode40~110kv0.5~5ma
(kv manual and automatic);
pulsd fluoroscopy 40~110kv 0,5-5ma
boost fluoroscopy 40~110kv 5~10ma;
photography 40~110kv 1~250mas
x ray tube dual-focus fixed anode:0.6mm1.5mm
italy imd technology
image intensifier three fields of vision 9, 6, 4.5 french thales brand
ccd camera japanese watt brand, 360â° rotation
image system 5 degree recursive noise reduction
frame freezing
thousands of image data storage
image conversing and rotating
screen display with image comparison
support �one click� print,print the image report
equip with dicom 3.0 network port(optional)
support dicom 3.0standard data export function
mechanical motion specifications verticaltravel:0-400mm horizontaltravel:0~200mm rotation about horizontal axis:â±180â°
c-arm dimension distance of focal spot to image generator(sid):1000mm
depth in arm�650mm mobile stand :1800mm*800mm*1850mm
image system: 750mm*530mm*1680mm
standard configuration high resolution ccd camera:1set
x-ray generator:1set
9� image intensifier:1set
image processor
23'' lcd high definition display 1 set
mobile stand :1 set
printer: 1set.
