    C Purlin Roll Forming Machine

    • Supply TypeManufacturer, Exporter, Supplier
    • Preferred Buyer Location All over the world

    Get your C Purlin Roll Forming Machine from Sanxing, a manufacturer, supplier and exporter of Steel Purlin Machines based in Yingkou, Liaoning. This equipment follows pre-cutting technique that....
    View More Details
    Send Enquiry

    Company Information

    • calendar Member Since 10 Years
    • building Nature of Business Manufacturer
    • Year of Establishment 1992

    Ask for more detail from the seller

    Contact Supplier
    Report incorrect details
    • Product Details

    • Company Details

    no_img_icon

    Get your C Purlin Roll Forming Machine from Sanxing, a manufacturer, supplier and exporter of Steel Purlin Machines based in Yingkou, Liaoning. This equipment follows pre-cutting technique that reduces time and cost. It beats its competition by cutting 500,000 times against an ordinary 20,000 times recorded by its competitors.
    More about C Purlin Roll Forming Machine : Our product is easy to install and shows outstanding anti-bending property.



    Features :

    • Unlike other C shape roll forming machines, it adopts pre-cutting, which can be used for a longer time than after-cutting, thus reducing your cost.
    • This metal forming equipment can cut about 500,000 times, whereas the ordinary machine can only cut 20,000 times at most.


    Application of C Purlin Roll Forming Machine :

    • The C-shaped purlines formed by this machine exhibit excellent anti-bending property and easy installation. They are widely applied as the supporter of roof and wall in
    • large-scale and mid-scale construction, such as factory, warehouse, garage, gymnasium, exhibition center, cinema, theatre and garden etc.


    Technical Specification Of C Purlin Roll Forming Machine

    C Purlin Section Size

    Model

    Section size(mm)

    Hole Distance
    (mm)

    Remarks



    h

    b

    c

    t



    Different models are available according to customer's requirements (middle holes are also available)

    c80

    80

    40

    15

    2.0-3.0

    none

    c100

    100

    50

    20

    2.0-3.0

    40

    c120

    120

    50

    20

    2.0-3.0

    adjustable

    c140

    140

    50

    20

    2.0-3.0

    adjustable

    c160

    160

    50

    20

    2.0-3.0

    adjustable

    c180

    180

    60

    20

    2.0-3.0

    adjustable

    c200

    200

    60

    20

    2.0-3.0

    adjustable

    c220

    220

    60

    20

    2.0-3.0

    adjustable

    c250

    250

    70

    20

    2.0-3.0

    adjustable

    NAME

    POWER

    REV

    PURPOSE

    Electric molding machine

    15Kw

    1440r/min

    molding

    Molding retarder



    39r/min

    molding

    The most figure size



    length

    size

    Height

    8500mm

    2000mm

    1700mm

    The most ability of produce

    C

    The weight of the machine

    About 8T

    We have three common types:
    1. seven types (product dimension), from 80mm to 200mm,
    2. seven types(product dimension), from 120mm to 250mm
    3. six types(product dimension), from 120mm-300mm.
