Cable Drum Jacks

We are offering cable drum jacks, cable drum handling.
specifications
cable drum jacks,cable drum handling ,cable handling equipment,hydraulic cable jack set,hydraulic cable drum jack,hydraulic lifting jacks for cable drums--bazhou dpair power tools cable drum jacks,cable drum handling
detailed descriptionuses for expanding the cable on six division rolling disk.features & benefitsthe hand to lift cable pay-off stand also called six division cable pay-off stand, uses for expanding the cable by external force on six division rolling disk.
cable drum jack&cable drum handling/cable handling equipment
product no.: dl011 product name: trapezoidal and hydraulic cable drum jack
application: applied in the supporting of cable drum. With trapezoidal structure, it can be applied in different kinds of reel specification. Hydraulic lifting make it lift easily, trundles installed on the bottom make it easy to move, simple operation, secure and durable.--bazhou dpair power tools cable drum jacks,cable drum handling
product no. rated load applicable drum diameter applicable drum width axle bar diameter dead weight
dl011-3 3t φ700mm-φ2100mm ≤1500mm φ60mm 90kg
dl011-5 5t φ700mm-φ2400mm ≤1700mm φ76mm 130kg
dl011-10 10t φ700mm-φ3200mm ≤1800mm φ120mm 210kg
product no.:crs-10 product name: hydraulic cable drum jack--bazhou dpair power tools
application: applied in the pay-off of outdoor underground cable, high altitude line stringing, indoor switchboard wiring, etc. With fixed seat during operation, the cable drum will not swing back and forth. Support high by oil pressure, simple operation, can be lifted quickly and easily.
product no. rated load applicable drum diameter applicable drum width axle bar diameter dead weight
crs-10 10t φ1800mm-φ2800mm ≤1800mm φ120mm 210kg
crs-15 15t φ1800mm-φ3200mm ≤2200mm φ120mm 260kg
crs-20 20t φ1800mm-φ3600mm ≤2400mm φ140mm 380kg
product no.: dl018 product name: mechanical cable drum jack--bazhou dpair power tools
product no. rated load applicable drum diameter applicable drum width axle bar diameter dead weight
dl018-1 1t φ1160mm-φ1700m ≤1000mm φ60mm 30kg
dl018-3 3t φ1400mm-φ2100mm ≤1400mm φ76mm 40kg
dl018-5 5t φ1600mm-φ2400mm ≤1600mm φ76mm 40kg
product no.: dl026 product name:cable drum reel rotator platform / elevator reel jack --bazhou dpair power tools
product no. rated load applicable drum diameter dead weight
dl026-4 4t ≤2200mm 55kg
dl026-6 6t ≤2500mm 65kg
dl026-8 8t ≤2700mm 80kg
cable drum jacks,cable drum handling.
