Cable Splicing Hydraulic Press

Model	CS/VH/125
For Use Off	Cable Slicing. (Vertical & Horizontal).
Max. Cable Size	125 mm.
Capacity	3 Ton.
No. of Cylinder	1 Nos.
Cylinder Travel	150 mm. [Adjustable].
Table Size	300 x 400 mm.
Maximum Working Pressure	180 kgs.
Slice Thickness	Adjustable Slice Thickness Cutting.
Power Pack	Adjustable Pressure Control Valve, Variable Speed Type.
Oil Tank Capacity	40 Liter. [Approx.]
Working Height	650 mm. [Approx.]
Standard Accessories	Breather, Oil Level, Section Filter, Liquid Feed Pressure Gauge.
Operating System	Reverse & Forward Push Button Type [Motor On/Off Switch].
Price	Rs. 1,57,000/-

Technical Specifications
Model	Cable Conductor removing Machine
For Use Off	Conductor Removing from Cable.
Body Type	Four Pillar Type.
Max. Cable Dia.	80 mm.
Capacity	3 Ton.
No. of Cylinder	1 Nos.
Cylinder Travel	150 mm. [Adjustable].
Table Size	150 x 150 mm.
Maximum Working Pressure	180 kgs.
Operating System	Up & Down Hand Lever Valve.
Punch	1 Set.
Price	Rs. 80,000/-

Model	Cable Conductor Remover Punch Mandrel
Conductor Diameter	11, 13, 15, 19, 23, 25, 18, 32, 35 mm. (9 Nos.)
Outer Ring for 11 mm Conductor	18, 20, 23, 25, 27, 29, 31, 34, 36, 38, 43, 45, 47, 51, 55, 57, 60, 64, 67 mm. (19 Nos.)
Price per Punch	Rs. 1200/-
Total Price of 28 Nos.	Rs. 33,600/-
