Cap Tpe Sheet Molding Machine

We are offering Cap Tpe Sheet Molding Machine (cap Lining Machine).
The machine can run with high speed so that you can get around 400-500pcs / minute. And each pad weight is only 0.25-0.3g .And special design for lower thickness in the center but keep the side sealing with preform very well.
This machine is mainly used to make pads for plastic bottle caps. It first fluidize the dry domestic and imported EVA/TPE granular plastic with high temperature and then mold presses the fluid on the inner cap.If without pads, water and gas leakage would occur as in the past. Moreover, the employment of manual pad placing is unsanitary in the first place. Second, it’s easy to place two pieces on one cap or miss to place. Third, the work efficiency is low. While this machine solves all the above problems. It’s compact, efficient and easy to operate. The pad produced with it is smooth and beautiful. The bottle cap with it opens easily and seals tightly. Furthermore, it conforms to the national food hygiene standard and possesses similar performance with imported caps and molding machines.
　
Thermal control:25mm-50mm Productivity:24000 to 30000 pcs/day
Pad weight:0.25-0.30g/pc Overall power consumption:11KW
Main engine power 3KW Absorbed electrical power Electrical relay, Coordinated control
Size(LXWXH) 3150X1100X1550mm Weight 1.6T
Voltage 440/380/220v
Thermal control:25mm-50mm Productivity:24000 to 30000 pcs/day
Pad weight:0.25-0.30g/pc Overall power consumption:11KW
Main engine power 3KW Absorbed electrical power Electrical relay, Coordinated control
Size(LXWXH) 3150X1100X1550mm Weight 1.6T
