Contact Supplier| Thread Size | Anchor Outside Dia (mm) | Thread Depth (mm) | Anchor length (mm) | (KGS)Pull Out Load kgs | (KG)Weight Kgs per 100 pcs |
| M6 | 8 | 10 | 25 | 850 | 6.3 |
| 1/4" | |||||
| M8 | 10 | 14 | 30 | 1350 | 12.5 |
| 1/4" | |||||
| M10 | 12 | 15 | 40 | 1950 | 25 |
| 3/8" | |||||
| M12 | 16 | 20 | 50 | 2900 | 51 |
| 1/2" | |||||
| M16 | 20 | 25 | 65 | 4850 | 112 |
| 5/8" | |||||
| M20 | 25 | 35 | 80 | 5900 | 235 |
