Carpet Pattern CNC Flatbed Cutting Plotter, Brand Name : CUTCNC

We are offering carpet pattern cnc flatbed cutting plotter which make sample and do small production. can cut max 15mm material. Carpet pattern cnc flatbed cutting plotter function:
1.it can cut many different materials (non-asbestos fiber, flexible graphite, inorganic fibre, modified ptfe styles)
2.it can fold corrugated paper, card paper and offset board into perfect folding line.
3.it can half cut ,whole cut,crease and dotted line.
4.using laser lamp improve location precision
5.using for sample maker or small batch of production.
Carpet pattern cnc flatbed cutting plotter parameter:
type dcp -2516d dcp -1713d dcp -1310d
effective cutting area 2500*1600mm 1700*1300mm 1300*1000mm
configuration oscillating blade. Pen. Creasing wheel.
Function it is used in carton& paper box packaging factory. It can cut and crease 15mm corrugated paper.
Max speed 1000mms
smallest cutting diameter 6mm
maximum cutting thickness 15mm
control line and driver servo
precision 0.1mm
vacuum 5.5kw
data form hpgl
voltage 220vâ±10% 50hz
data port pci port
data transmission speed 10mbs
using dimension(mm 315*2380*1150 2370*2200*1150 1960*1890*1150.
