Contact SupplierFeatures
Micro-computer control, PVC operation keyboard, automatic testing
Dynamic digital-display of the test numbering and pressure, specimen distortion and initial pressure
4 testing modes: distortion under defined pressure, pressure under defined distortion, maximum pressure and stack tests
Single-phase power, direct-current drive, presetting function of test speed
Built-in mini printer
Overload protection, malfunction alarm, maximum stroke protection
Light-weight design, suitable for various floor loads
Technical Indexes
Test range: 15kN, 45kN (optional)
Accuracy: ±1% of reading force
Resolution of force: 1daN
Resolution of distortion: 0.1mm
Test speed: 5, 10, 12.7mmmin
Test space: 1m(L) x 1m(B) x 1.3m(H)
Power: AC 220V 50Hz60Hz
Dimensions: 1.2m(L) x 1.5m(B) x 2.3m(H)
Net weight: 800kg
Standards
ASTM D642, ASTM D4169, TAPPI T804, ISO 12048, JIS Z0212, GBT 16491, GBT 4857.4
