NAUGRALABS LABORATORY PRODUCT NAME: CBR TEST APPARATUS (HAND OPERATED) FOR TESTING LAB
NaugraLabs Laboratory Product Code: NLE-Export-015049

Description and Specification for Lab Tenders

CBR Test Apparatus (Hand Operated).

This apparatus comprises of : A hand operated load frame 50kN capacity. A mould of 150 mm. I.D. x 175 mm. high with clamping lugs complete with extension collar and perforated base plate made of gun metal. A cutting collar to fit mould body.

A penetration piston assembly of 50 mm. diameter and a bracket for the dial gauge. A perforated swell plate of 148 mm. diameter with an adjustable stem and lock nut. A circular spacing disc of 148 mm. diameter x 47.7 mm. high complete with a removable `T' handle. A metal tripod for the dial gauge. Surcharge weight : annular 2.5 kg., 147 mm. diameter. Surcharge weight : slotted _ 2.5 kg., 147 mm. diameter. civil lab equipments manufacturers
