    Sorting Conveyor Candle Perfume Filtration System, Certification : CE Certified, ISO 9001:2008 Certified
    • Candle Perfume Filtration System
    • 703940
    • 703941
    • 703942
    • 703943
    • 703944

    Sorting Conveyor Candle Perfume Filtration System, Certification : CE Certified, ISO 9001:2008 Certified

    ₹ 30,000 / Set
    Get Latest Price
    • MOQ01 Set(s)
    • MaterialSorting Conveyor,Tubular Preheated Pasteurizer,Pulping Machine
    • Brand NameAarkays, Airtech Cooling, Eskay, YUDO-SUNS
    • CertificationCE Certified, ISO 9001:2008 Certified, MS ME
    • Power1-2kw, 1-3kw, 10-12kw, 2-4kw, 3-6kw, 4-6kw, 6-8kw, 6-9kw, 8-10kw, 9-12kw
    • Supply TypeManufacturer, Exporter, Supplier
    • Preferred Buyer Location All over the world
    View More Details
    Send Enquiry

    Company Information

    Microtech Engineeringverified-icon
    location Krishna Vihar, Delhi
    4.6/5fill iconfill iconfill iconfill iconhalf icon(30)
    View Number
    • calendar Member Since 14 Years
    • building Nature of Business Exporter
    • gst icon GST No. 07AASFM3267H1ZV

    Ask for more detail from the seller

    Contact Supplier
    Report incorrect details
    View Company Details

    • Product Details

    • Company Details

    no_img_icon

    • Number Of FlowerIndustrial Filtration Systems, Filtration System
    • Brand NameAarkays, Airtech Cooling, Eskay, YUDO-SUNS
    • CertificationCE Certified, ISO 9001:2008 Certified, MS ME
    • Country of Origin110V, 220V, 380V, 440V
    • ConditionNew
    • Power1-2kw, 1-3kw, 10-12kw, 2-4kw, 3-6kw, 4-6kw, 6-8kw, 6-9kw, 8-10kw, 9-12kw
    • Total Carbohydrate1year
    • MaterialSorting Conveyor,Tubular Preheated Pasteurizer,Pulping Machine
    • ApplicationFiltration
    • FeatureDurable, Easy To Use, Fine Finished, Flawless Functioning, High Performance, Reliable, Rust Proof
    • Weight100-1000kg, 1000-2000kg, 2000-3000kg, 3000-4000kg, 4000-5000kg
    • Driven TypeElectric, Solar
    • Automation GradeAutomatic, Fully Automatic, Manual, Semi Automatic

    Microtech engineering offer offer candle perfume filtration system with candle cleaning system electrical flameproof.
    Salient Features

    • All contact parts made out of s. S. 304 l material.
    • No requirements of any filter pad / filter.
    • S. S. Candle for crystal clear filtration & long lasting.
    • Option - pump can be use separately for water transfer or usually with the filter press


    Technical Specifications

    Model
    No. Of candles4 nos6 nos
    Filtering candlesS. S. 316 / 10-20 micronS. S. 316 / 10-20 micron
    Output(ltrs/hr)800-1500 ltrs/ hr/2000-3000 ltrs/ hr/
    Liquid holding‘0’ after full transfer‘0’ after full transfer
    Thickness of shell3mm thick3mm thick
    Thick of top- bottom cover5 mm thick5 mm thick
    Length of candle200 mm200 mm
    Inlet conical filter6” dia x s. S. Mash6” dia x s. S. Mash
    Process inlet outlet1” dia hose nipple1 ½ ” dia hose nipple
    Direct use pump connection1” bsp ball valve / 1 ½ ” hose nipple.1 ½ ” bsp ball valve / 1 ½ ” hose nipple.
    Candle cleaning system1 candle clean at a time1 candle clean at a time
    Pump mechanical sealS. S. 316 PTFE.S. S. 316 PTFE.
    Pump motor2hp / 440 rpm / 3 ph / flame-proof3 hp / 440 rpm / 3 ph / flame-proof
    Air vent- safety valve¼ BSP.¼ BSP.
    Drain valve1” BSP1” BSP
    M. O. CS. S. 304 l / 316S. S. 304 l / 316
    FinishPolished to mirror finish.Polished to mirror finish.

    Additional Information

    • Payment Terms L/C, D/A, D/P, T/T, Western Union
    • Port of DispatchALL COUNTRY
    • Packaging DetailsWOODEN BOX.
    • Delivery TimeREADY STOCK
