Ceiling Woofer

The optional Square Grille Adapter allows speakers to match the aesthetic of square downlights and HVAC grilles to achieve continual sight lines.
An ultra-high-excursion 8” polypropylene woofer delivers effortless and impactful low bass extension and augmentation, at any sound pressure level, making it the perfect partner for the PS-C43RT and PS-C63RT In-Ceiling Speakers.
A full-fidelity transformer delivers uncompromised sonic performance in either high (70V, 100V) or low (8 Ohm) impedance.
The PS-C83RWT features a sealed metal enclosure, integrated cable and conduit clamping, removable Euroblock connector with loop-through, swing-open connecter cover and seismic attachment. Additionally, the Sonance PS-C83RWT is certified for UL 1480 and UL 2043.Frequency Range (-10dB)
Frequency Range (-3dB)
Power Capacity
Nominal Sensitivity
Nominal Coverage Angle
Directivity Factor (Q)
Directivity (DI)
Rated Maximum SPL
Rated Impedance
Transformer Taps
Crossover Point
Overall Dimension
Cut Out Dimension
Net Weight
Shipping Weight
Unit of Measure
Grille
LF Driver
HF Driver
Input Connector
Knockout
Safety Agency
Maximum Ceiling Thickness
Suspension Points
PS-C83RWT
PS-C83RWT
32Hz – 300Hz
50Hz – 150Hz
200 Watts Continuous Program Power | 125 Watts Continuous Pink Noise
89 dB
180 degrees conical coverage
NA
NA
110dB @ 1 meter (3.3 feet) average, 116dB peak
8 Ohms nominal, 6 Ohms minimum
120W, 60W, 30W, (15W 70V)
150Hz
11.06” Diameter x 9.84” Depth (281mm x 250mm)
10.125” (257mm)
12 lbs (5.44kg) each
18 lbs (8.61kg) each
Each
Supplied with bezel-less white grille. Optional black grille, or square adapter with black or white grille
8” (203mm) Polypropylene Cone, Butyl Rubber Surround
NA
Four pin Euroblock with loop output connections
One, side mounted .75”
UL 1480, UL 2043, NFPA 90A, NFPA 70
1.732” (44mm)
One, on top surface
