Contact SupplierCement silo (cement tank) composition
The composition of cement silo (cement tank) is as follows: steel silo part, ladder, guardrail, feeding pipe, dust collector, pressure safety valve, level gauge, discharge valve and so on.
Cement silo (cement tank) structure
Cement silo (cement tank) for the cylindrical structure, the bottom of the four cylinder tube leg support the entire silo, the entire silo for all steel structure, welded together; the top of the precipitator and the pressure relief valve.
Cement silo (cement tank) Model parameters:
Model Tank Diameter Tank Height The total height of the silo Matched mixer screw conveyor
30T 2.5m 4.8m 11.4m JD350 LSY 163 type
50T 3m 5.4m 12m JS500 LSY 180 Type
80T 3m 9m 15.6m JS750 LSY 180 type
100T 3m 11.4m 18m JS1000 LSY 230 type
150T 3m 23.5m 29m JS1000 LSY 230 series
200T 4.5m 18.6m 25.2m JS1500 LSY 230 series
300T 4.5m 24.6m 29.5m JS2000 LSY 230 series
500T 6M 22.2m 28.8m JS3000 LSY 230 series
