China Dalian Supplier: Ultrasonic Level Meter (hlml)

1 .Resolution 1mm/1cm
2.Measuring error : 0.2%( full range)
3.Display : Two lines ,14 letters,LCD Display (back light )
4.Signal output : DC 4-20mA RS485
5.Outpot load : 0-500Ω
6.Relay output : higher alarm /lower alarm
7.Relay mode : always open
8.relay quatity: 2 or 4
9,relay specification : 5A 250VAC /30VDC
10 RS485 standard level
11.power supply : HLMLD : DC24V (±10%) 0.1 A
HLMLA: AC220V(±20%) 0.1 A
12.Measure Cycle :1 second ( can change)
13: Temperature : -40ºC~85ºC
14.Crust Material :ABS
15.Outer cover :IP67
16.Cable Fix: PG9/PG11/PG13.5
17. Parameter Set Up： 3 induction buttons
18.Installation :wall mount ,clamp on
19.Dimension : 186*183*126mm
