CK5118 CNC Vertical Turning Lathe VTL Machine

Product name :CNC vertical turning lathe VTL machine CK5118
Application fields of CNC vertical turning lathe machine CK5118
This machine is used for various rough and finish turnings including internal and external cylindrical surface, conical surface, end face and grooving.
CNC Vertical turret lathe machines VTL machine model:
CK5112CK5116CK5118CK5120CK5123CK5125CK5126
CK5225CK5232CK5240CK5250CK5263 CK5235
Technical specification of CNC vertical turning lathe VTL machine CK5118
1 Table diameter 1400 mm
2 Maximum turning diameter 1800 mm
3 Maximum height of workpiece 1000 mm
4 Maximum weight of workpiece 5 t
5 Speed change of table 5-160 rmin
6 Rotation speed of work table 16
7 Feed rates 0-1000 mmmin
8 Step stepless
9 Horizontal travel of tool post 1000 mm
Vertical travel of tool post 800 mm
10 Horizontal travel of side cutter bar 630 mm
Vertical travel of side cutter bar 900 mm
11 Crossrail travel 650 mm
12 Maximum section scale of tool bar 30×40 mm
13 Power of main motor 30 kw
revolutions 1470 rmin
14 Power of Feed motor 1.31.7 kw
Revolutions 9401440 rmin
15 Rapid travelling speed of tool post 2000 mmmin
16 Machine weight 17.5 t
17 Overall dimensions(L×W×H) 2900×2900×3800mm
