CK6140 CNC LATHE MACHINE, Brand Name : darway

Ck6140 cnc lathe machine with siemens 808d in russianenglish
ck6140 boxway cnc lathe (flat bed)
1. specification
ck6140
max. Swing over bed
φ400mm
max. Swing over cross slide
φ250mm
max. Turning length
chuck 600 mm
collet 700 mm
spindle bore
485282mm
bar capacity
3665mm
spindle speed
150-1800
spindle nose
a2-6a2-8
main motor power
7.5kw inverter motor
xz axis position accuracy
0.010.015mm
xz axis repeatability
0.0120.013mm
xz axis motor torque
46 n.m
xz axis motor power
11.5kw
xz axis rapid speed mmin
810
tool post type
46 tool electric turret
toolholder
20*20mm
tailstock quill dia.
Φ60mm
tailstock quill travel
100mm
tailstock taper
mt4
n.w.
1800kg
machine dimension (l*w*h)
2200*1100*1620mm
2. Features
high rigidity pedestal and wider lay board are suitable for heavy cutting
6-tool electric turret, inverter stepless speed
3. Usage
it can automatically process the inside and outside cylinder surface, cone surface, circle arc surface,
end face. It can also turn the single and multiple threads in metric , inch and other standard.
4. Standard accessories
siemens 808d cnc system in englishrussian language with english language control panel
inverter motor 5.5kw, 6-station electric turret, 200 mm hydraulic thru-hole chuck
hydraulic tailstock, integrated automatic lubrication system, coolant system, light system
