CL5: Free Chlorine Sensors

Listing ID #3831997

Get Latest Price

Accuracy ± 0.5% / 1.0% of F.S
Display Nil
ParameterCL
Max Pressures Upto 7 Bar
Supply Type Manufacturer, Exporter, Supplier

Preferred Buyer From : All over the world

View More Details

Send Enquiry

Product Details

Accuracy ± 0.5% / 1.0% of F.S
Display Nil
Power Supply 24V AC
Range 0 to 20 ppm
Parameter CL
Max Pressures Upto 7 Bar

The CL series (free chlorine sensors) feature amperometric measurement technology. Designed for disinfection applications in water treatment,for,pools,etc.,these sensors are available in three ranges for detecting ppm level of free chlorine. Choose the CL502 for 0-2ppm, CL505 for 0-5ppm and CL510 for 0-10ppm of free chlorine
Typical applications include:
Industrial wastewater
Cooling water
Bottle rinsing
Irrigation water in agriculture
Sensors output a 4-20mA signal scaled to 0-2 or 0-10ppm. Membrane cap
and fill solution are easily replaceable to maximize sensor life.
Sensors can be used in new installations with Omicron's flow cell or installed
as replacement for other 4-20mA output free chlorine sensors.
(Consult Omicron for compatibility).
An optional flow meter (FM001) is available to help provide consistent flow
for added system stability.

Special Features :

	Amperometric Sensor Technology
	Real Time Continuous Measurement
	Ranges: 0-2, 0-5 or 0-10ppm
	Built-In Temperature Compensation
	Large Electrolyte Reservoir
	Replaceable Membrane and Electrolyte

Measuring Range	0-2, 0-5 or 0-10 ppm free chlorine
pH Range	5.5 - 8.5
Body Material	PVC
Membrane Cap Material	PVC housing, Proprietary Membrane
Temperature Range	0 - 45 Degrees C
Maximum Pressure	14.7 psig (1 Bar)
Temp Comp	Integrated
Cable Length	10 feet 2 conductors, tinned leads
Process Connection	flow cell 1/4 inch FNPT threads
Output	4-20mA
Flow Range	Min 0.2 gpm (45 l/hr), Max 0.6 gpm (135 l/hr)
Supply Voltage	12-24V DC , 250mA minimum
Cross Sensitivity	Chlorine dioxide, Ozone, bromine, iodine
