max drilling capacity 20mm
max end milling capacity 16mm
size of work table(LxW) 800x240mm
T slot 16 x 3 x60mm
Max loading weight of work table 60kg
X & Y & Z Axis 420mm
290mm
Distance between spindle nose and table 50 -450mm
Distance between spindle center and column 297mm
Spinlde taper ISO30/BT30
Max spindle speed 4000 or 6000rpm
spindle motor power 1.5kw
Feeding motor power x axis 1kw
y axis 1kw
z axis 1kw
Rapid feeding speed X,Y,Z axis 6m/min
Feding speed 0-2000mm/min
Min.setting unit 0.01mm
Max size of tool 60x 175mm
Loosing and clamping way for tool manually
Max loading weight of tool 3.5kg
Net weight 735kg
Packing size 1220x1380x1650mm
