Description Unit VG-X760 VG-X650
X、Y、Z Stroke Mm 600*700*350 500*600*230
Table Dimension（L*W） mm 600*800 600*500
Max. Load of the Table Kg 500 400
Spindle Power Kw 5.5 4
Revolution Rpm 15000RPM 18000/24000
Spindle Spring Clamper ER ER25 ER25/ER20
Max. Diameter of the Tool ф 20 16/13
Max. No-load Feedrate m/min 15 15
Max. Cutting Feedrate m/min 8 8
Cnc Controller LNC-600I LNC-600I
Positioning Precision 300mm ±0.003 ±0.003
Repeat Positioning Precision 300mm 0.002 0.002
Lubricating Systems Automatic Automatic
Rated Input Voltage V 380±10% 380±10%
Net Weight Kg 4200 ≈3200
Max. Pass of the Gantry (X*Z) mm 660*400 640*285
