Cnc plasma cutting machine, Rated Power : 1-7kw

We are offering cnc plasma cutting machine,
1, the gas source control panel
gas from the gas valve and pressure gauge: air pressure machine at a glance.
2, cnc system
shanghai jiaotong university, usa haibao, usa burny10, australia fastcnc, canada profiler multiple cnc systems to choose
3, the longitudinal rails
using heavy rail from finishing u71mn
4, cnc cutting torch
assembled according to customer needs cnc flame single separatism, dusting crossed torch, punching and beating device, plasma machine torch cutting torch or line three. Automatic adjusting device can also be fitted.
5, the main beam cutting machine
beam welded square beam structure, through tempering eliminate mechanical stress, then precision machinery processing, ensuring beams permanent deformation, and its high strength and good rigidity. Assembling precision grinding on rails and precision steel rack and pinion, ensuring reliable lateral movement precision. Horizontal rack is bolted to the beam for easy replacement and adjustment.
6, horizontal towline
trachea for cnc torch cable transmission, the ability to work with continuous fatigue.
7, strip transmission mechanism
driven carriage carriage through steel bent and active synchronous movement.
8, the vertical drive end beam
driving side with guide wheels, ensure that the whole process in motion with a stable orientation. Drive frame end faces were fitted scraping plates, ready sweeping debris accumulated on the surface of the rail.
