Contact Supplier| MODEL | SA-02-CO2 | SA-03-CO2 | SA-4.5-CO2 |
|---|---|---|---|
| Capacity | 2kg | 3kg | 4.5kg |
| Confirming IS Code | 15683 | 15683 | 15683 |
| Type of Cylinder | Manganese Steel Cylinder (IS:7285) ISI Mark & PESO (CCE) Approved | ||
| Type of Operating Valve | Wheel/Squeeze Grip Type (IS:3224) | ||
| Expellant | Carbon Dioxide Gas (CO2) | ||
| Diameter (Approx) | 108 ± 10 mm | 140 ± 10 mm | 140 ± 10 mm |
| Height (Approx) | 530 mm | 545 mm | 700 mm |
| Filled Weight (Approx) | 9.0 kg | 12.0 kg | 16.5 kg |
| Empty Weight (Approx) | 7.0 kg | 9.0 kg | 12.0 kg |
| Average Discharge Time | 9.0 sec. | 11.0 sec. | 14.0 sec. |
| Operating Temperature | -20°C to 60°C | ||
| Working Pressure at | 20°C 90 bar | ||
| Maximum Service Pressure | 100 bar | ||
| Hydraulic Test Pressure | 250 Kg/cm2 | ||
| Fire Rating | 21B | 34B | 55B |
| Approvals | BIS & CE | BIS & CE | BIS & CE |
