Co2 laser cutting machine

We are offering co2 laser cutting machine for acrylic wood metal sheet.
co2 laser cutting machine for acrylic wood metal sheet
if interested in our laser cutting machine,laser engraving machine,laser marking machine,laser embroidery machine,welcome to e-m-a-i-l kelly li for price list,videos and specifications.
laser cutting vs. Mechanical cutting
laser cutting machines are distinct from traditional mechanical cutters. Since the laser never makes physical contact with the metal, there is little to no wear on the equipment, and there is less opportunity for the material to become contaminated. Laser cutting machines also cut metal with higher precision than that of mechanical means.
advantages of golden laser solution for metal and solid materials:
cost efficiency by the application of low maintenance technologies and maintenance-free lasers
engrave and cut a wide variety of materials
one machine cutting both metal and non-metal
faster speed and higher precision
global pioneer for dual core laser processing system
particular ultrasonic auto-focus system
high efficiency engraving and cutting in one machine (two independent systems)
high efficiency galvanometer engraving and cutting integrated technology
international leading laser motion control system
auto-nesting
fast pattern digitizing
complete exhaust and filtering of cutting emissions possible
ergonomic loading and unloading system without time-consuming
jmscjg-130250dt high precision co2 laser cutting machine
main technical parameter�
laser type: coherent / synrad co2 rf metal laser tube
laser power: 400w (standard collocation)
100w / 150w / 200w / 300w (optional collocation)
working area: 1300mmã�2500mm (1300mmã�1600mm / 1300mmã�900mm)
working table: strip panel working table
working speed: adjustable
repeating location accuracy: â±0.1mm
cooling system: constant temperature water chiller
motion system: servo motor, lcd display, ball screw driving system
power supply: ac110v-220v 50/60hz
format support: ai, bmp, plt, dxf, dst, etc.
standard collocation: mini air compressor, automatic control high pressure blow valve
optional collocation: automatic following focusing system
machine dimension: 4.40ã�2.22ã�1.32(m)
packing size: 4.50ã�2.30ã�1.50(m)
co2 laser cutting machine application
applicable materials: perfectly cutting metal and non-metal materials, such as stainless steel, mild steel, carbon steel, acrylic, wood, mdf, die board, plywood, veneer, plastic, plexiglas, plexiglass, perspex, pmma, abs, rubber, sponge, paper, cardboard, paperboard, cardstock, etc.
applicable industries: sheet metal processing, advertising & signs, led letters, decorative letters, advertising letters, metal sign letters, crafts, decoration, printing and packaging industry, modelling, furniture & floor manufacturing, parquet, marquetry and those which are in need of cutting both metal and non-metal materials.
co2 laser cutting machine features
1) large format working area with steel girder structure.
2) precision ball screw driving system and servo motor system ensure high cutting precision.
3) coherent / synrad co2 rf metal laser tube produces high quality laser beam, stable power and long working life. Low use-cost, maintenance-free and high efficiency.
4) strip panel working table reduces contacting area with work pieces, which ensures high quality cutting.
5) following exhaust system has good air suction performance, saving energy consumption.
6) smart nesting function enhances utilization rate of processing material.
7) 5 inches lcd cnc system provides online and offline for your choice, easy to use.
8) wide application. Suitable for cutting metal and non-metal. It is a multi-purpose machine that can cut up to 30mm thick non-metal materials like acrylic and wood and also can cut up to 3mm thick metal sheets.
[we also supply co2 laser cutting engraving machines for flexible materials, yag laser cutting and marking machines and fiber laser cutting and marking machines. ]
