Co2 Laser Machine - Cantilever Structure

We are offering co2 laser machine - cantilever structure.
brief introduction
b6015 laser cutter is a precision cnc laser cutter equipped with the fast axial flow co2 laser with international advanced technology such as high precision gear rack (gudel switzerland), servo motor (siemens, germany), digital control system assembly pa8000(germany), capacitive vertical tracking system assembly (precitec,germany),pneumatic system assembly(smc japan ), electrical system assembly(schneider),etc.
feature
1 cantilever structure
2 perfect openness and easy to load and unload
3 both sheet metal and pipe cutting are available
4 customized is available
technical parameter (for b3015)
performance indicator parameter
processing surface (l × w) 3000 mm × 1500 mm
x axle stroke 3040 mm
y axle stroke 1530 mm
z axle stroke 120 mm
positioning accuracy of x, y and z axles ±0.03 mm
repeated positioning accuracy of x, y and z axles ±0.02 mm
maximum positioning speed of x and y axles 85 m/min
cnc system pa8000
maximum load of workbench 900 kg
phases 3
parameter of rotary workable
processing diameter scope 20-380mm
processing length 3m
maximum length 180mm*12m
maximum rotary speed 39.5r.p.m
location precision 0.15
repeating location precision 0.03
processing pipe thickness 0.5-16mm
