CO2 Laser Marking Machine

CO2 Laser marking machine principle:
CO2 laser is one kind of gas laser with which laser wavelength is at 10.6um and CO2 is the working medium. When high voltage is enforced on the poles, discharging tube full of CO2 will discharge and generate laser. After amplifying its energy, the discharged laser can be used for processing
Adopts high-performance RF laser
Adopts high-speed scan head and high-performance RF laser(imported from USA), the marking is high speed, high precision, good stability, have the ability of long working time. The software is based on Windows, can work with CorelDRAW, AutoCAD etc drawing operation software, can mark all the kinds of drawing, words and bar code, support all the kinds of common used drawing and words format,coding, serial number printing, batch number and date Applications:
The CO2 laser engraving machine is used for marking on non-metals. It is widley used in leather, wood, textile, plastic, label, packaging, crafts, electronics, communications, clocks and watches, eye glasses, printing, and decorations
The CO2 laser engraving machine specifications:
Maximum laser power: 10/30/50/100W
Wavelength: 10.64um
Repetitive frequency: ≤20kHz
Engraving depth: ≤2/3/5/8mm
Marking area: 110 x 110mm (others are available)
Linear speed: ≤7,000mm/s
Minimum letter: 0.20mm; 0.40mm
Minimum line width: 0.05mm; 0.10mm; 0.15mm
Repetitive accuracy: ±0.01mm
Laser source: imported
Consumed power: 800W/1.2kW/2kW/4kW
Electricity requirements: 220V/50Hz/3.5A; 220V/50Hz/8A; 220V/50Hz/11A; 220V/50Hz/20A
