Contact SupplierType of refective glass | Light transmittance tv (%) | Light reflectance pv p'v (%) | Direct solar transmittance iE (%) | Direct Solar refectance PE (%) | Total solar energy transmittance g (%) incidence on coating resp. Glass | ||||
|---|---|---|---|---|---|---|---|---|---|
Clear
| 4mm | 50.10 | 36.90 | 31.80 | 56.50 | 27.10 | 22.10 | 60.70 | 62.00 |
6mm | 41.70 | 44.50 | 38.00 | 49.40 | 32.20 | 25.60 | 54.10 | 55.90 | |
Dark Blue
| 4mm | 29.10 | 34.20 | 14.10 | 46.10 | 24.90 | 16.00 | 53.60 | 55.90 |
6mm | 18.70 | 42.00 | 11.30 | 36.80 | 30.70 | 14.90 | 45.20 | 49.30 | |
Lake blue
| 4mm | 29.50 | 46.70 | 24.40 | 34.60 | 33.50 | 17.70 | 42.80 | 46.90 |
6mm | 21.80 | 53.10 | 21.30 | 24.20 | 38.80 | 15.50 | 33.70 | 39.80 | |
Dark green
| 4mm | 33.40 | 44.00 | 25.80 | 33.80 | 31.40 | 15.60 | 42.80 | 46.90 |
6mm | 25.10 | 50.40 | 23.10 | 24.30 | 36.50 | 13.00 | 34.40 | 40.50 | |
French green
| 4mm | 33.60 | 48.70 | 34.00 | 31.00 | 34.90 | 19.50 | 39.80 | 43.80 |
6mm | 25.60 | 57.60 | 35.80 | 20.60 | 42.40 | 18.80 | 30.10 | 36.20 | |
Mist
| 4mm | 29.70 | 39.00 | 16.20 | 37.00 | 28.10 | 13.00 | 46.00 | 49.90 |
6mm | 21.10 | 44.10 | 13.20 | 26.90 | 32.00 | 11.00 | 37.50 | 42.90 | |
Pink
| 4mm | 38.70 | 43.40 | 29.20 | 52.50 | 32.00 | 21.40 | 56.50 | 59.20 |
6mm | 30.40 | 51.10 | 29.00 | 45.30 | 37.30 | 21.20 | 49.80 | 53.90 | |
The information contained in the above table is provided as a guide and the specifaction may vary from the indicated figures. The information contained herein does not imply and contractual obligation on the part of the supplier.
