Cold Room PU Sandwich Panel With With Cam Lock

We bring forth suitable PU Sandwich Panel with Cam Lock for the global market. We are reputed to be among the leading Manufacturers, Exporters, and Suppliers of Cold Room PU Sandwich Panel with With Cam Lock from China. The insulation property of the cold room is exceptional and so is its quality. Rely on us!

 Details :

• Refrigeration cold room and freezer, with fruit storage freezer room, Connected by type of eccentric locks, With better air tightness close and better insulation effect, Also has disassembling easily and can be flexible mobile, Cold storage can be assembled to be various size and capacity on various places.
• According to various requirements of customers the refrigerator production use various materials combination, cold storage floor interior surface and buried steel or wood square reinforcement.
• Some cold storage directly using strip PU do bottom in its upper berth on certain thickness of cement to make floor board. Strong and durable Suitable for hotel kitchen.

Panel Details :

• Panel width : 960 and 1000mm
• Panel length : 12000mm
• Steel thickness : 0.4/0.5/0.6/0.8mm
• Regular steel sheet color code : RAL 9002 (grey white)
• PU density : 40 ±2kg/m3
• Heat transfer coefficient : 0.024W/m*k
• Bending strength : 331Mpa
• Fire rating : B2
• Surface of panels: Can choose any type of surface materials
• Standards : JB and T6527 to 2006

Cold storage panel option (by various materials):

• Stainless steel
• Painted galvanized steel
• Galvanized steel
• Number base plate thickness and applicable temperature range :

  • 75mm medium temperature (-5^OC or above)
  • 100mm low temperature (-30^OC or above)
  • 150-200mm ultra low temperature (-45^OC or above)

Applications :

• Food : Meat, vegetable, fruit, dairy and drink
• Medicines
• Chemicals
• Electronics
