System 6 utp
max® modules
system 6 utp end-to-end cabling solution, the system 6 max module provides performance far exceeding category 6 connecting hardware performance specifications.
Its compact design is ideal for high density applications. Up to six modules can be utilized in a single gang faceplate and twelve modules in a double gang faceplate. Also, the angled max module provides a gravity feed, low-profile design for the work area — greatly improving patch cord management in installations where clearance is at a minimum.
Flexible installation — install from either front or rear
of faceplate
easy termination — terminates with standard 110
termination tools
quick identification — icons provided for port
identification
backward compatible — with category 5eclass d
system components
universal wiring — t568a and t568b wiring
compatible
protective doors — minimize exposure to dust and
quick installation
pyramid wire entry system on s310®
blocks separates paired conductors
when lacing cables to simplify and
reduce installation time.
Termination
palm guard with max insert
(pn: pg-mx6) assists in securing module
during termination.
Superior performance
for superior performance use system 6
mc modular cords to unlock the
performance of system 6 max modules.
