Computerized NC Cutting Machine

We are enlisted among the successful Manufacturers, Exporters and Suppliers of Computerized NC Cutting Machine. The machines we make available allow storage of cutting specifications quickly and accurately to provide for non-stop operation support as per the specific process requirements. We offer the cutting machines at market-leading prices from us.
Details :

• The system also comes with knife shaft eccentric shaft mounted drive gear for high transmission accuracy.
• Some of its features include cross knife blades with front set pieces, stable flat blade holder structure, long blade life, wear-resistant finish, cast iron based main base and wall, servo motor drive controller, capability of handling different cutting length from 300 mm to 9000 mm while providing cutting accuracy of 1.5 mm

Features :

• Can store 1000 groups of order
• Cutting specifications quickly and accurately, non-stop
• For a single, and the realization of computer networking
• To facilitate the production and management.
• Knife shaft eccentric shaft mounted drive gear, backlash
• Free transmission, transmission accuracy.
• Cross knife blades with front set pieces.
• Flat blade holder structure, more stable and more suitable
• For high cutting board weight and high toughness, shear
• Force is small, long blade life.
• Led by outsourcing non-slip materials, paper roll, more
• Wear-resistant, accurate size.
• The main base and wall with high-grade gray cast iron,
• High strength, vibration and strong.
• Servo motor drive controller, 5.7 inch color touch screen
• Display, the project at a glance.
• Cutting length: 300mm-9000mm, cutting accuracy: ± 1.5mm
• (When the steady speed).

General Specifications :

• The maximum working width: 1400mm
• The maximum mechanical speed: 50m/min
• The minimum cutting length: 300mm
• Maximum cutting length: 9000mm
• Cutting accuracy: ± 1.5mm uniform as
• All the rollers have been grinding, hard chrome plated Department
• (Except for tool axis) management.

Power Motor and electrical parameters : The main drive motor power - 3KW AC synchronous servo control of the whole a chain of paper motor power - 3KW (Frequency Control)
