Computerized Vickers Hardness Testing Machine, Weight : 70 Kg

₹ 1.25 Lakh - ₹ 1.75 Lakh / piece

Brand NameAditya Instruments
Weight70 Kg
Power Supply220VAC,50HZ,1 Ph
Total Loads5,10,20,30,50 Kgf.
Supply TypeManufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Product Details

Brand NameAditya Instruments
Total Loads5,10,20,30,50 Kgf.
Maximum test Height200mm
Scale Least Count0.001mm
Diagonal Measuring Range0.05 to 0.4mm
Throat Depth135mm
Machine DimensionL 585 x W 290 X H 860 mm
Weight70 Kg
Power Supply220VAC,50HZ,1 Ph

We, Aditya Instruments are one of the leading manufacturers of Computerized Vickers Hardness Testing Machine is simple & accurate in design. It is appropriate for measuring the hardness of accuracy metallic parts with a wide testing range from soft to hard & their precise results are widely acclaimed. Some of the special features of our tester are :

Small indentation allows testing of precision finished parts.

Thin sheet metals are perfectly tested. Because the applied load is very small.

Motorized loading and unloading cycle.

Internally Built-in projection screen to get exact results.

The same firmness number is acquired on the same specimen, regardless of the load applied.

Extensive testing range, from soft metal such as lead, up to the most solid, like hardened steel.

For world class Vickers Hardness Testing Machine, contact us now.

Features:

Fully Computerised (PC Based) Vickers Hardness Machine.
Directand accurate measurementof Vickers Hardness Number using "State of Art"
Image processing technology.
High accuracy and repeatability of measurementat all loads.
Faster measurement yielding to higher productivity.
Motorised loading and unloading cycle.
Small loads allow testing of thin sheet metals.
Wide testing range':from soft metal such as lead up to medium hardened steels.
Small size of indentation makes ita non-destructive testing on finished components.
Advanced Window 95/NT based software.

Latest GUI Features :

Canbe connected to Laptop or Desktop PC. Easyto carry anywhere and handy for use with easy setup.
Minimum Petnium-ll with 64 MB RAM.
Windows 98 Operating System. (PC not included in standard scope of supply.)
One USB 2.0 and one RS232 (serial) interface (9 pin) is required and itis
Recommended for Laptop to use external USB to serial converter for RS232 interf

PC requirements :

Online indentation setting and focusing on PC monitor.
User-friendly software with all help file and Window Features.
Advance image processing: Algorithms implemented for precise alculation of hardness numbers with various options to cover all ranges of specimen.
