Contact SupplierWe are a prime Manufacturer, Supplier and Exporter of Concrete Batching Plant from India. Our Concrete Batching Plant is highly demanded among the clients owing to its qualitative features such as high performance and longer working life. These Concrete Batching Plants can be availed in various models to cater the clients requirement.
Options For Various Machines
Models | SR 500E / 500D | SR 750E/SR750D | SR 1 OOOE/l OOOD |
---|---|---|---|
Hopper Capacity | 550 Liters | 800 Liters | 1050 Liters |
Batch Capacity | 450 Liters | 600 Liters | 750 Liters |
Machine Output/Hour | 9 Cu.M./Hr. | 12 Cu.M./Hr. | 15 Cu.M./Hr. |
Power | 10HP | 10 HP | 15 HP. |
Water Tank Capacity | 150 Liters | 180 Litres | 260 Litres |
Weighing System | Load Cell based weighing System with digital display. |
Load Cell based weighing System with digital display. |
Load Cell based weighing System with digital display. |
Hydraulic Pump | 25 Imp Gear Pump @ 160 Bar | 25 Ipm Gear P.ump @ 180 Bar | 30lpm Gear Pump @ 200 Bar |
Wheel | Pneumatic Wheels (4Nos) 6 X 16 | Pneumatic Wheels (4Nos) 6X 16 | Pneumatic Wheels (4Nos) 7 X 16 |
Jack Leveling | Box Type (4Nos) | Box Type (4Nos) | Box Type (4Nos) |
Unloading Hight | 1225mm | 1225mm | 1425mm |
Overall Dimensons(mm) | L-3700 x W-2200 x H-2800 | L-3900 x W-2200 x H-3100 | L-4000 x W-2350 X H-3250 |
Weight(kgs) | 2200 Kg(Approx) | 2350Kg(Approx) | 2600Kg(Approx) |
Note : We reserve the right to make changes and improvements in design without prior notice. Performance of the machine are based on standard working conditions
